Roof Steel Bar Structure Detail 6000x9000mm Slab Layout Drawing

This detailed Roof Steel Bar Structure Detail drawing, prepared in AutoCAD DWG format, covers a complete 6000x9000mm slab layout for residential spaces, including kitchen and dining room areas. The drawing presents roof reinforcement plans with beam grid dimensions, column placements, and steel bar distribution with clear sectional references. It includes light aligerada slab detail with rib spacing, joist configuration, slab thickness, and structural support alignment. Section detail drawings clearly define reinforcement positioning, concrete cover, and bar bending arrangement for accurate site execution. The layout ensures structural stability with properly marked measurements, cross sections, and elevation coordination.
