Irrigation System Main Longitudinal Profile DWG with Sections

This AutoCAD DWG file provides a detailed irrigation system design with main longitudinal profiles, sectional drawings, and elevation views. Each profile includes precise gradient lines, dimensioned pipe layouts, and cross-sectional data to facilitate accurate planning and installation. The drawing covers multiple profiles, showing pipe alignment, slope calculations, and flow direction for optimal irrigation coverage.

Engineers, landscape architects, and civil designers can use this file for designing efficient irrigation systems in agricultural fields, parks, and urban landscaping projects. It includes comprehensive tables for pipe sizing, elevation markers, and flow rates, making it easy to integrate into project plans. With clearly marked sections, the drawing ensures accurate execution and easy referencing during construction, helping professionals maintain precision in large-scale irrigation layouts.
