Concrete Block Wall Corner Connection Section Plan 0.15m Detail

This Concrete Block Wall Corner Connection Section Plan 0.15m Detail drawing presents a technical masonry junction showing the connection of hollow concrete block walls in a square frame configuration. The plan and sectional detail clearly illustrate block dimensions of 0.15m thickness with a 0.40m wall return length at the corner. The drawing identifies hollow block cells filled with concrete grout and reinforced with 3/8 inch diameter vertical steel bars positioned within the core. The L-shaped reinforcement arrangement is detailed to ensure structural stability at the wall intersection. All dimensions are precisely marked, and the section representation highlights block alignment, grout filling zones, and reinforcement continuity.
