Bridge Abutment Wall Section Detail with Foundation Dimensions

This bridge abutment detail drawing presents a structural wall section and elevation showing the construction arrangement of an abutment wall with foundation support. The AutoCAD drawing illustrates the abutment wall structure connected with the base foundation and ground support layers. The section clearly represents reinforced wall construction, base footing thickness, and the connection between the wall and the foundation system. Structural layers such as concrete base, compacted soil support, and wall reinforcement alignment are illustrated with accurate construction measurements. The drawing also shows the structural relationship between the wall section and the surrounding ground level, which helps maintain stability and load distribution in bridge or retaining structures.
