Here Concealed horizontal fan coil unit with outside air mounted details. finished ceiling , duct size to suit supply air grille , drain pan and pipe connection , filter access door , return air grille , 15mm collar size to suit flexible duct furnished , flexible duct for flexible air , hanger rod support secure to structure above , duct size to suit supply air grille , coil A horizontal fan coil is designed for a ceiling installation, while a vertical fan coil is designed for a wall installation. In building HVAC systems, multiple fan coils are connected to the same piping loop, which carries chilled water or hot water as needed. an coil unit (FCU) is a device that uses a coil and a fan to heat or cool a room without connecting to duct work. Indoor air moves over the coil, which heats or cools the air before pushing it back out into the room. heat pumps must start with what they are and what they have in common. Unlike air conditioners and furnaces, fan coil units and heat pump systems are both capable of heating and cooling your home. They both can also maintain the humidity levels , for more details of Concealed horizontal fan coil unit with outside air mounted download this file .
