Power supply electric energy detail dwg drawing, AutoCAD file


Description

Power supply electric energy detail including A power supply is an electrical device that supplies electric power to an electrical load. The main purpose of a power supply is to convert electric current from a source to the correct voltage, current, and frequency to power the load. As a result, power supplies are sometimes referred to as electric power converters. also show front, side and top view and plan  an electronic circuit that converts the voltage of an alternating current (AC) into a direct current (DC) voltage. It is basically consisting of the following elements: transformer, rectifier, filter and regulator circuits. For more details of Power supply electric energy download this AutoCAD file ,dwg format or 2d drawing.




File Type: DWG File ID: 254422
