Hydraulic pipe blender top view details AutoCAD file, cad file,dwg format


Hydraulic pipe blender top view details including  bend die, clamp die, pressure die, wiper die, and mandrel. It works by using the pressure sequence created by hydraulic motor and this equipment is applied largely in bending hard metal pipes. He markings O, R and L, these are the bend alignment markings which indicate to the user how far to pull the handle round the former. For more details of Hydraulic pipe blender parts download  AutoCAD file, cad file,dwg format.

File Type: DWG File ID: 254775
