This Architectural Drawing is AutoCAD 2d drawing of Reinforced detailing on foundation level in AutoCAD, dwg file. Reinforcement in the foundation is needed to ensure the continuity of the structure. This is particularly important in cases of bad ground or where the building may be subjected to earthquake forces. The reinforcement is assumed to be deformed high yield steel bars which are commonly supplied in the OECS.
