Modern Hotel AutoCAD DWG Plan with Room Layout and Elevation Design

This modern hotel plan AutoCAD DWG file presents a complete architectural drawing package featuring detailed floor layouts, guest room arrangements, reception lobby, service corridors, staircase cores, lift shafts, and utility areas. The project is designed on an approximate site size of 70 x 32 meters with a built-up area of nearly 5200 square meters distributed across multiple floors. Standard room sizes of around 3.5 x 4.2 meters, corridor widths of approximately 2.1 meters, and floor heights of nearly 3.3 meters are clearly marked. The drawing includes a wall thickness of 230 mm for external walls and 115 mm for internal partitions, along with grid lines, column positions, and accurate dimension annotations for professional construction planning.
