Hotel Project Master Plan Layout With Site Dimensions design

This Hotel Project master plan layout presents a detailed site development drawing with complete dimensions, plot boundary lines, internal road network, parking areas, landscape zoning, and building footprints clearly marked. The drawing includes setback measurements, circulation pathways, green zones, entrance exit planning, and organized block positioning to support structured hotel planning. Grid references, annotation tags, and scaled layout elements provide accurate spatial coordination for architectural and civil execution of the Hotel Project.
