This AutoCAD drawing provides complete column design details and reinforcement specifications for Type-IV Quarters at NSG Campus, Lekhawada, Ahmedabad. It covers typical reinforced concrete columns, shear wall openings, splicing details, and column reduction in Zone 3, designed as per IS:456-2000, IS:1893 (Part-1):2016, and IS:13920-2016.

The design includes column lap lengths (50d–65d), development length (Ld+10), and special confining reinforcement spacing ?100mm. Columns are detailed with M30–M50 concrete grades and Fe550D reinforcement steel.

Clear cover varies by element: footing/raft (75mm/50mm), columns (40mm), beams (25mm), slabs (20–25mm), RCC walls (40mm), and water tanks (40mm).

It also includes hook types (135°/180°), tie and stirrup arrangements, construction joint key details, and epoxy protective coatings.
