Simple Office Design Drawing with Floor Layout Section and Elevation

This simple office design drawing is a complete AutoCAD documentation set prepared for municipal and small commercial office planning. The drawing includes detailed floor layout plans showing organized workspaces, cabins, circulation corridors, stair access, and service areas planned to scale. Clear dimensions are provided in metric units, including room sizes, wall thicknesses, passage widths, and door and window placements to support accurate execution. The layout reflects functional zoning for administrative use with efficient movement and supervision. Electrical layout plans are included, indicating lighting points, power sockets, switch locations, and wiring coordination for office operations and safety compliance.

The simple office design detail file also contains section plans, elevation drawings, and construction planning details that define building height, floor-to-floor levels, plinth height, roof profile, and façade proportions. Structural references and level markers support coordination between architectural and construction drawings. This AutoCAD DWG file is suitable for architects, civil engineers, interior designers, and builders working on municipal offices, small office buildings, and institutional projects. The drawing is compatible with AutoCAD and can be coordinated with 3D Max, Revit, and Google SketchUp workflows, making it a practical resource for approvals, design development, and construction documentation.
