Combined Column Footing Design Drawing with RCC Anchorage Details

This combined column footing design drawing presents a detailed AutoCAD representation of an RCC foundation system with anchorage and reinforcement details. The drawing illustrates a combined footing layout supporting reinforced concrete columns, showing footing depth, width, and slab thickness with accurate dimensional annotations. Structural elements such as foundation beams, footing slabs, and column starters are clearly defined with reinforcement bar sizes, spacing, and anchorage lengths. Steel plate anchorage details are included at the column base, showing bolt placement, nut and washer arrangements, and load transfer from steel elements into reinforced concrete. Concrete grades and reinforcement specifications are clearly marked to support structural clarity.
