House Layout Design Drawing with Rooms Furniture and Facilities

This House Layout Design AutoCAD drawing presents a well-planned residential floor layout with detailed room zoning and furniture arrangement. The drawing includes bedroom areas, kitchen, hall, living room, dining space, bathrooms, and toilet layouts with clear circulation flow. Specialized spaces such as swimming pool, fitness center, sauna, dressing rooms, mechanical rooms, and storage areas are also shown. Furniture placement, like beds, seating units, dining tables, poolside seating, and gym equipment, is accurately represented to support functional planning. Door swings, wall thicknesses, stair layout, and room labels are clearly marked for professional architectural coordination.

The house layout design further illustrates internal connections between living areas, service zones, and recreational spaces. Bathroom layouts include sanitary fixtures with proper clearances, while kitchen and dining areas are arranged for efficient movement. The plan supports residential and leisure-oriented design requirements, making it suitable for large house or villa planning. This AutoCAD DWG file is useful for architects, civil engineers, interior designers, and builders preparing residential planning drawings, interior layouts, and construction documentation. The drawing is compatible with AutoCAD, 3D Max, Revit, and Google SketchUp, enabling accurate drafting, visualization, and project coordination.
