Coffrage formwork of the ground floor, solid slab details, waterproofing details of the structure, cross section of arch etc. with reinforcement details in AutoCAD drawing


Coffrage formwork of the ground floor, level of formwork +4.57 specified. Solid slab sections with reinforcement details are given. Waterproofing details of the terrace are given in this drawing. Cross section G’-G’ of the arch with reinforcement details are also given. Steel component design with formwork and reinforcement details are available in the drawing. For more knowledge and information download the drawing file.
