Sky Light at Double Pitch Roof with Steel Structure and Glazing

This AutoCAD DWG file provides detailed drawings of a skylight installed on a double-pitch roof with a steel structure, showing precise dimensions for glazing panels, steel beams, roof pitches, and anchor connections. The drawing includes sectional views of roof profiles, glazing support frames, waterproof membranes, and structural steel members, offering architects, civil engineers, and builders a comprehensive guide for accurate installation and integration. Each component is annotated with exact measurements for roof slopes, beam spacing, glass panel sizes, and connection details to ensure structural stability and weather resistance. CAD professionals can efficiently visualise, edit, and integrate this skylight and roof structure into residential or commercial building projects. Fully layered and compatible with AutoCAD, Revit, SketchUp, and 3D Max, this DWG supports precise material estimation, construction planning, and seamless execution of double-pitch roof skylight designs.
