RCC Stair Detail 3.60m x 6.00m Plan Section Structural Drawing

RCC Stair Detail 3.60m x 6.00m Plan Section Drawing presents a comprehensive architectural and structural layout showing stair placement within a 3.60m x 6.00m building footprint. The drawing includes plan view and section A A with clearly marked RCC slab, tread, and riser configuration, landing detail, and vertical circulation alignment. Road level, plinth level, and O T L A references are accurately indicated for site coordination. The sectional view highlights stair slope, step dimensions, slab thickness, and wall connections to ensure proper load transfer and construction accuracy.

The plan also defines internal spatial arrangement around the stair core with wall thickness, entry position, and circulation path. Detailed measurements illustrate riser height, tread width, landing extension, and structural slab support within the RCC framework.
